| Specification | UNIT | APC-110B | APC-160B | APC-200B | APC-250B | APC-315 | |||||
| Model | V | H | V | H | V | H | V | H | V | H | |
| Capacity | Ton | 110 | 160 | 200 | 250 | 315 | |||||
| Rated tonnage point | mm | 5 | 3 | 6 | 3 | 6 | 3 | 7 | 3.5 | 7 | 3 |
| Stable speed | s.p.m | 35-65 | 50-100 | 30-55 | 40-85 | 25-45 | 35-70 | 20-35 | 30-60 | 20-35 | 30-50 |
| Stroke | mm | 180 | 110 | 200 | 130 | 250 | 150 | 280 | 170 | 300 | 170 |
| Die height | mm | 400 | 435 | 450 | 485 | 500 | 550 | 550 | 605 | 550 | 450 |
| Slide adjustment | mm | 100 | 100 | 120 | 120 | 120 | |||||
| Bolster area | mm | 1800x650x130 | 2000x760x150 | 2400×840×170 | 2700×900×170 | 2800x950×190 | |||||
| Slide area | mm | 1400×500×70 | 1600×550x70 | 1850x650×95 | 2100x700×95 | 2100×700×95 | |||||
| Main motor | KwxP | 11×4 | 15×4 | 18.5×4 | 22×4 | 30x4 | |||||
| Air pressure | kg/cm² | 6 | 6 | 6 | 6 | 6 | |||||
| Presses precision | GB/JIS 1class | ||||||||||
| Presses dimension | mm | 1820x2000x3100 | 1940×2200x3709 | 2235×2620x3849 | 2545×3000x4304 | 3100×2750x4950 | |||||
| Capacity | Ton | 14.2 | 20 | 27.5 | 45.5 | 48 | |||||
| Die cushion work part dimension | mm² | 350x235×2 | 410×260×2 | 540x350×2 | 640x470×2 | 640×470×2 | |||||
● In order to guarantee the machine running in stable and smooth, adopts the design of symmetrical two slid boards with balancer.
● The precision of mold adjusting up to 0.1mm, safety, reliable and convenient.
● Crank, gear, connect bar are oxidized hardening and milled, having super comprehensive mechanical performance and du urable function.
● Reasonable structural design, is convenient for automatic production and line production.
● Used reliable high intensity cl tch/brake and twin electromagnetic valve, overloading protector can gu larantee safe production all-around.
● Used high-grade alloy steel, double crank, wide work center with connection bar structure, the optimized design is suitable for large sizes and the mold bearing large impact loading as well as pressing of eccentric mold.
● Adopted closed electric loop circuit, have compatible with any automatic equipments.
